English-14
Preparation
IMPORTANT: Do not apply pressure to the TV screen display area which
may compromise the integrity of the display� The manufacturer’s warranty
does not cover user abuse or improper installations�
Attaching the Base
E654
Stand Screw x 4
E654:M6 (16mm)
E554 / E464 / E424
Stand Screw x 4
E554/E464/E424:M4 (10mm)
E324
Stand Screw x 4
E324:M4 (8mm)
Neck Screw x 4
E324:M4 (12mm)
1� Place the TV face down on a soft and at surface to prevent scratching
and damage�
2� Carefully align the base to the stand and fasten the screws with a cross-
head screwdriver�
CAUTION: The base of the stand is very heavy� Install with care to avoid
injury such as dropping the base onto one's foot�
To Next Page
