Install on the wall
4 inches
10 cm
4 inches
10 cm
4 inches
10 cm
Leave at least this space
around the set.
11 7/8 inches
30 cm
2.36 inches
6 cm
For use only with UL Listed Wall Mount Bracket with minimum weight / load:
Please refer to the Specication on page 36 and page 39 �
Unit without base weight: The equipment and its associated mounting means
still remain secure during the test�
Used wall mounting kit, VESA-compatible wall bracket distance, diameter of
Screw dimension: Please refer to the Specication on page 36 and
page 39 �
