NEC E464 - Timing and Resolution Specifications

English-27
English-26
English
Timing Table
Resolution
WXGA
(E324)
FHD
(E654/E554/E464/
E424)
Horizontal Vertical
Nominal
Pixel
Clock
(MHz)
VGA DVI VGA DVI
Nominal
Freq.
(kHz)
Sync
Polarity
Nominal
Freq.
(Hz)
Sync
Polarity
640 × 480@60Hz ● ● ● ● 31�469 – 59�94 – 25�175
720 × 400@70Hz ● ● ● ● 31�469 – 70�087 + 28�322
800 × 600@60Hz ● ● ● ● 37�879 + 60�317 + 40
1024 × 768@60Hz ● ● ● ● 48�363 – 60�004 – 65
1280 × 720@60Hz ● ● ● ● 45 – 60 + 74�25
1280 × 800@60Hz ▲ ▲ ● ● 49�702 – 59�81 + 83�5
1366 × 768@60Hz
●
(Native)
●
(Native)
Not
support
● 47�712 + 59�79 + 85�5
1920 × 1080@60Hz ▲ ▲
●
(Native)
●
(Native)
67�5 + 60 + 148�5
Resolution
WXGA
(E324)
FHD
(E654/E554/E464/E424)
HDMI Component HDMI Component
480i 60Hz ● ● ● ●
480p 60Hz ● ● ● ●
720p 60Hz ● ● ● ●
1080i 60Hz ▲ ▲ ● ●
1080p 24Hz ▲ Not support ● Not support
1080p 30Hz ▲ Not support ● Not support
1080p 60Hz ▲ Not support ● Not support
NOTE:
▲: Use Down-scaling function. Image quality is limited.
