Express5800/R320a-E4, R320b-M4(Windows2008 R2 model)
18
UPS
[Note]
- Be sure to manage the UPS via network with Network shutdown software. The UPS can
not be managed via serial port and USB port with Power Chute Plus software.
Example configuration (UPS Non-Redundant ):
APC UPS (3000VA)
(3,000VA/2,700W)
Network management Card
LAN
Control
1400VA/1390W
Device Expansion Unit
[N8141-41F]
NEC Express5800/R320a-E4,
R320b-M4 [N8800-155F/154F]
450VA/400W
Note)
The UPS can not be managed via serial
port and USB port with Power Chute Plus
software.
