NEC LCD Monitor User Manual

(34/137)
Item OP
code
page
OP code Parameter Remarks
PIP INPUT(SUB INPUT) 02h 73h 0: No mean
1: VGA
2: RGB/HV
3: DVI
4: HDMI (Set only)
5: VIDEO
7: S-VIDEO
12(0Ch): Y/Pb/Pr
13(0Dh): OPTION
14(0Eh): Y/Pb/Pr2
15(0Fh): DPORT
16(10h): DPORT2
17(11h): HDMI
18(12h): HDMI2
128(80h): DPORT3
This operation
has limitation of
selection.
Please refer to
the monitor
instruction
manual.
RESET
(PIP)
02h CBh 0: No mean
6: Reset PIP
Category
Momentary
LANGUAGE 00h 68h 0: No mean
1: ENGLISH
2: GERMAN
3: FRENCH
4: SPANISH
5: JAPANESE
6: ITALIAN
7: SWEDISH
9: RUSSIAN
14(0Eh): CHINESE
OSD Language
MENU DISPLAY TIME 00h FCh 0-1: Do not set.
2: 10s
3: 15s
|
48(30h): 240s
5sec/step
X 02h 38h 0: Left
|
255(FFh): Right
OSD POSITION
Y 02h 39h 0: Down
|
255(FFh): Up
INFORMATION OSD 02h 3Dh 0:Disable information
OSD
3-10(0Ah):
OSD timer [seconds]
MODEL NAME Refer to chapter 12
SERIAL Refer to chapter 12
FIRMWARE1 Refer to chapter 16
FIRMWARE2 Refer to chapter 16
CARBON
SAVINGS
10h 10h
(g)
/11h
(kg)
0 – 999(3E7h)(g)
0 – 65535(FFFF
ｈ )(kg)
Read Only
MONITOR
INFORMATION
CARBON
USAGE
10h 26h
(g)
/27h
(kg)
0 – 999(3E7
ｈ )(g)
0 – 65535(FFFF
ｈ )(kg)
Read Only
OSD TRANSPARENCY 02h B8h 0: No mean
1: OFF
2: ON
OSD
OSD ROTATION 02h 41h 0: Landscape
1: Rotated
