NEC LCD Monitor User Manual

(35/137)
Item OP
code
page
OP code Parameter Remarks
INPUT NAME
NAME RESET
Refer to chapter 18
MEMO 10h BAh 0: No mean
1: Display a Memo
2: Undisplay a Memo
RESET
(OSD)
02h CBh 0: No mean
7: Reset
OSD category
Momentary
MONITOR ID 02h 3Eh 1-100:ID
GROUP ID 10h 7Fh 0: No assignment
1: Group A
2: Group B
3: Group AB
4: Group C
5: Group AC
|
1023(3FFh):Group
ABCDEFGHIJ
Bit0:Group A
Bit1:Group B
Bit2:Group C
Bit3:Group D
Bit4:Group E
Bit5:Group F
Bit6:Group G
Bit7:Group H
Bit8:Group I
Bit9:Group J
AUTO ID Refer to chapter 17
AUTO ID RESET Refer to chapter 17
IR LOCK SETTING 02h 3Fh 0: No mean
1: NORMAL
4: LOCK
H MONITOR 02h D0h 0: No mean
1
|
10(0Ah)
Number
of H-division
V MONITOR 02h D1h 0: No mean
1
|
10(0Ah)
Number
of V-division
POSITION 02h D2h 0: No mean
1
|
100(64h)
TILE COMP 02h D5h 0: No mean
1: NO
2: YES
TILE MATRIX
ENABLE 02h D3h 0: No mean
1: NO
2: YES
TILE MATRIX MEM 10h 4Ah 0: No mean
1: COMMON
2: INPUT
AUTO TILE MATRIX SETIP Refer to chapter 19
POWER ON DELAY 02h D8h 0: Off (0sec)
|
50(32h): 50sec
LINK TO ID 10h BCh 0: No mean
1: OFF
2: ON
VIDEO OUT SETTING 10h EAh 0: No mean
1: ON
2: OFF
POWER INDICATOR 02h BEh 0: No mean
1: ON
2: OFF
MULTI DISPLAY
SETTING COPY Refer to Chapter 21
