NEC LCD Monitor User Manual

(36/137)
Item OP
code
page
OP code Parameter Remarks
RESET
(MULTI DISPLAY)
02h CBh 0: No mean
8: Reset
Multi Display
Category
Momentary
POWER SAVE Refer to Chapter 20
FAN1/2/3 02h 7Ah
/7Bh
Select target FAN. (7Ah)
0: No mean
1: FAN#1
2: FAN#2
3: FAN#3
Read status of target
FAN.(7Bh)
0: OFF
1: ON
2: ERROR
Read Only
BACKLIGHT Refer to Chapter 11 (Self-diagnosis status read)
HEAT
STATUS
TEMPERATURE
SENSOR1/2/3
02h 79h Return value is 2’s
complement.
(0.5°C  step)
Offset affects to
a selected
sensor.
Select sensor
(Page02h
OPcode78h)
1 : SENSOR #1
2 : SENSOR #2
3 : SENSOR #3
COOLING FAN 02h 7Dh 0: No mean
1: AUTO
2: ON
FAN SPEED 10h 3Fh 0: No mean
1: HIGH
2: LOW
SENSOR1 10h E0h/E1h E0h: Set centigrade
0 – 65535(FFFFh)
E1h: Set
offset from max.
value
0 – 10(0Ah)
SENSOR2 10h E2h/E3h E2h: Set centigrade
0 – 65535(FFFFh)
E3h: Set
offset from max.
value
0 – 10(0Ah)
FAN CONTROL
SENSOR3 10h E4h/E5h E4h: Set centigrade
0 – 65535(FFFFh)
E5h: Set
offset from max.
value
0 – 10(0Ah)
GAMMA 02h DBh 0: No mean
1: OFF
2: ON
BACKLIGHT 02h DCh 0: No mean
1: OFF
2: ON
INTER
VAL
02h DDh 0: OFF(0s)
|
90(5Ah): 900s
10s/step
SCREEN SAVER
MOTION
ZOOM 10h 35h 0 : 95%
|
5 : 100%
|
10(0Ah) : 105%
DISPLAY PROTECTION
SIDE BORDER COLOR 02h DFh 0: Black
|
100(64h): White
