8. Appendix
[M402H]
Optical
Model Number NP-M402H
Projection
System
Single DLP® chip (0.65", aspect 16:9)
Resolution*
1
1920 X 1080 pixels (Full HD)
Lens Manual zoom and focus
Zoom Ratio = 1.7
F=2.4 - 3.2, f=18.0 - 30.6mm
Lamp 270 W AC
(219 W in NORMAL)
(162 W in ECO)
Light Output*
2
*
3
4000 lumens
NORMAL: 81%
ECO: 60%*
4
Contrast Ratio*
3
(full white: full
black)
10000:1 with DYNAMIC CONTRAST ON
Image Size
(Diagonal)
30–300 inches/0.76 m–7.6 m (16:9)
Projection
Distance
(Min.–Max.)
29"-319" (wide) / 52"-554" (tele)
0.75m-8.10m (wide) / 1.32m-14.08m (tele)
Projection Angle 16.9°-17.9° (wide) / 9.9°-10.2° (tele)
*1 Effectivepixelsaremorethan99.99%.
*2 Thisisthelightoutputvalue(lumens)whenthe[PRESET]modeissetto[HIGH-BRIGHT].Ifanyothermodeisselectedasthe
[PRESET]mode,thelightoutputvaluemaydropslightly.
*3 CompliancewithISO21118-2005
*4ThemaximumpowerbecomesequivalenttopowerinECO(ECOMODE).
Electrical
Model Number NP-M402H
Inputs 1 × RGB/Component (D-Sub 15 P), 2 × HDMI Type A (19P, HDMI
®
Connector) HDCP supported*
5
,
1 × Video (RCA), 1 × (L/R) RCA Audio, 1 × Stereo Mini Audio
Outputs 1 × RGB (D-Sub 15P), 1 × Stereo Mini Audio
PC Control 1 × PC Control Port (D-Sub 9P)
Wired LAN Port 1 × RJ-45 (10BASE-T/100BASE-TX)
Wireless LAN
Port (Optional)
IEEE 802.11 b/g/n (optional USB Wireless LAN Unit required)
USB Port 1 × Type A, 1 × Type B
MIC Input 1 × Monaural Mini Audio
Color Reproduc-
tion
10-bit signal processing (1.07 billion colors) (USB-A, LAN: 16.7 million colors)
Compatible
Signals*
6
Analog: VGA/SVGA/XGA/WXGA/Quad-VGA/SXGA/SXGA+/WXGA+/WXGA++/UXGA/WSXGA+/HD/Full HD/WUXGA/Mac13"/Mac16"/Mac
19"/Mac 21"/Mac 23"
Component: 480i/480p/720p/1080i (60Hz), 576i/576p/1080i (50Hz), DVD Progressive (50/60Hz)
Digital: VGA/SVGA/XGA/WXGA/Quad-VGA/SXGA/SXGA+/WXGA+/WXGA++/WSXGA+/HDTV (1080p)/HDTV (1080i)/HDTV (720p)/
SDTV(480p)/SDTV(576p)/SDTV(480i)/SDTV(576i)
3D: For PC XGA/1280 × 720/WXGA, For Video SDTV (480i), For HDMI-1.4a 720p (Frame Packing)/
1080p (Frame Packing)/1080i (Side by Side (Half))/720p (Top and Bottom)/1080p (Top and Bottom)
*5 HDMI
®
(DeepColor,LipSync,3D)withHDCP
 WhatisHDCP/HDCPtechnology?
 HDCPisanacronymforHigh-bandwidthDigitalContentProtection.HighbandwidthDigitalContentProtection(HDCP)isasystem
forpreventingillegalcopyingofvideodatasentoveraHigh-DenitionMultimediaInterface(HDMI).
 IfyouareunabletoviewmaterialviatheHDMIinput,thisdoesnotnecessarilymeantheprojectorisnotfunctioningproperly.With
theimplementationofHDCP,theremaybecasesinwhichcertaincontentisprotectedwithHDCPandmightnotbedisplayed
duetothedecision/intentionoftheHDCPcommunity(DigitalContentProtection,LLC).
 Video:DeepColor;8/10/12-bit,LipSync
 Audio:LPCM;upto2ch,samplerate32/44.1/48KHz,samplebit;16/20/24-bit
*6 Animagewithhigherorlowerresolutionthantheprojector’snativeresolution(M402H:1920×1080)willbedisplayedwithAdvanced
AccuBlend.
