26
2. Projecting an Image (Basic Operation)
[M402W/M362W/M322W/M402X/M362X/M322X/M282X/M402H]
1. Press the ▼ ( ) button on the projector cabinet
withnomenusdisplayed.
The Keystone screen will be displayed on the screen.
• PresstheKEYSTONEbuttonwhenusingtheremote
control.
2. Press the ▼buttontoselect[VERTICAL]andthen
use the ◀ or ▶sothattheleftandrightsidesofthe
projectedimageareparallel.
* Adjusttheverticalkeystonedistortion.
Projected area
Screen frame
3. Aligntheleft(orright)sideofthescreenwiththe
left(orright)sideoftheprojectedimage.
• Usetheshortersideoftheprojectedimageasthe
base.
• Intherightexample,usetheleftsideasthebase.
Align left side
4. Press the ▲buttontoselect[HORIZONTAL]andthen
use the ◀ or ▶sothatthetopandbottomsidesof
theprojectedimageareparallel.
• Adjustthehorizontalkeystonedistortion.
5. Repeat steps 2 and 4 to correct keystone distor-
tion.
