English−16
For box contents, please refer to the printed contents sheet or setup manual provided in the box.
The accessories included depends on the location where the monitor was shipped.
1. Place the monitor face down on a non-abrasive surface ().
2. Please rotate the monitor stand 90 degrees as shown in .
Please refer to “CAUTION 6”.
3. Attach the base to the stand, then tighten the screw at the base’s
bottom ().
Reverse this procedure if you need to re-pack the monitor.
Please refer to “WARNING 8”.
Please connect the power cord and signal cables to the monitor (see page 14).
Hold the monitor on each side and adjust the screen position as desired.
For screen rotation (pivot), hold the monitor on each side, lift to its maximum height and turn it from landscape to portrait.
Please refer to “CAUTION 6” and “CAUTION 9”.
Screw
90°
To Next Page
