NEC MultiSync EX231Wp User Manual

English
English-15
ECO Information
CARBON SAVINGS: Displays the estimated carbon savings information in kg.
COST: Displays the electricity cost savings in balance.
INTEGRAL POWER: Displays the multiple value of the power consumption.
CARBON CONVERT SETTING: Adjusts the carbon footprint factor in the carbon saving calculation. This initial
setting is based on the OECD (2008 Edition).
CURRENCY SETTING: Displays electricity pricing in 6 currency units.
CURRENCY CONVERT SETTING: Displays electricity savings in kW/hour (US Currency is default).
NOTE: This model’s initial setting is “Currency = US$” and its Currency Convert setting = $0.11.
This setting can be changed by using the ECO information menu.
If you want to use the French setting, please refer to steps below:
1. Open menu by touching the Menu Key and select the ECO information menu using the left or right
slide key.
2. Select Currency setting by sliding the Up or Down key.
3. The French currency unit is Euro (
). You can adjust currency setting to Euro icon ( ) from US dollar
icon ($) by using the Left or Right key.
4. Select Currency Convert Setting by using the Up or Down slide key*.
5. Adjust Currency Convert Setting by using the Right or Left slide key.
* This initial Euro ( ) setting is Germany of OECD (2007 Edition).
Please check receipt of French’s electricity prices or OECD data for French.
French of OECD (2007 Edition) was
0.12.
Information
The Information menu indicates the current input, display resolution, horizontal and vertical frequency, and polarity
settings of the monitor. The model and serial numbers of your monitor are also indicated.
OSD Warning
OSD Warning menus disappear with MENU (EXIT) Key.
NO SIGNAL: This function gives a warning when there is no Horizontal or Vertical Sync. After power is turned on or
when there is a change of input signal, the No Signal window will appear.
OUT OF RANGE: This function gives a recommendation of the optimized resolution and refresh rate. After the power
is turned on or there is a change of input signal or if the video signal doesn’t have proper timing, the Out Of Range
menu will appear.
NOTE: It is possible to change the IPM settings or DVI Selection while the “NO SIGNAL” or “OUT OF RANGE”
messages are displayed.

NEC MultiSync EX231Wp Specifications

General

3D	No
Pixel pitch	0.27 x 0.27 mm
Aspect ratio	16:9
Response time	25 ms
Composite sync	Yes
Display diagonal	23 \
Video input impedance	75 Ω
Contrast ratio (dynamic)	-
Contrast ratio (typical)	3000:1
Display number of colors	16.78 million colors
Digital vertical frequency	56 - 75 Hz
Digital horizontal frequency	31.5 - 83 kHz
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
VGA (D-Sub) ports quantity	0
Intelligent mode	IPM
Certification	Energy Star 5.0 TCO 5.2 EPEAT Gold RoHS
Product color	Black
Height adjustment	110 mm
Panel mounting interface	100 x 100 mm
Power consumption (typical)	27 W
Power consumption (PowerSave)	0.37 W
Cables included	DVI, USB, VGA
Bundled software	NaViSet
Operating altitude	0 - 2000 m
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 85 %
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Bezel width (top)	16.4 mm
Bezel width (side)	14.6 mm
Depth (with stand)	215 mm
Height (with stand)	511.3 mm
Weight (with stand)	4200 g
Depth (without stand)	47.7 mm
Width (without stand)	540.2 mm
Height (without stand)	318.3 mm
Weight (without stand)	2800 g
