Specifications - EX231Wp
Monitor Specifications MultiSync EX231Wp Notes
LCD Module Diagonal: 58.42 cm/23.0 inches Active matrix; thin film transistor (TFT) liquid
Viewable Image Size: 58.42 cm/23.0 inches crystal display (LCD); 0.265 mm dot pitch;
Native Resolution (Pixel Count): 1920 x 1080 250 cd/m
2
white luminance; 3000:1 contrast ratio,
typical (25000:1 Contrast ratio, Dynamic).
Input Signal
DVI: DVI-I Connector: Digital RGB DVI (HDCP)
Analog RGB 0.7 Vp-p/75 ohm
Sync Separate sync.TTL level Positive/Negative
Composite sync.TTL level Positive/Negative
Sync on Green
(Video 0.7 Vp-p and Sync Negative 0.3 Vp-p)
DisplayPort: DisplayPort Connector: Digital RGB DisplayPort Complies with Standard V1.1a,
applicable to HDCP
Display Colours 16,777,216 Depends on display card used.
Synchronization Range Horizontal: 31.5 kHz to 83.0 kHz (Analog) Automatically
31.5 kHz to 83.0 kHz (Digital) Automatically
Vertical: 56.0 Hz to 75.0 Hz Automatically
Viewing Angle Left/Right: ±89° (CR > 10)
Up/Down: ±89° (CR > 10)
Image Formation Time 25 ms (Typ.)
Resolutions Supported 720 x 400*
1
: VGA text Some systems may not support all modes listed.
640 x 480*
1
@ 60 Hz to 75 Hz
800 x 600*
1
@ 56 Hz to 75 Hz
832 x 624*
1
@ 75 Hz
1024 x 768*
1
@ 60 Hz to 75 Hz
1152 x 870*
1
@ 75 Hz
1280 x 1024*
1
@ 60 Hz to 75 Hz
1440 x 900*
1
@ 60 Hz
1400 x 1050*
1
@ 60 Hz to 75 Hz
1680 x 1050*
1
@ 60 Hz NEC DISPLAY SOLUTIONS cites recommended
1920 x 1080 @ 60 Hz............................. resolution for optimal display performance.
Active Landscape: Horiz.: 509.8 mm/20.1 inches
Display Area Vert.: 286.7 mm/11.3 inches
Portrait: Horiz.: 286.7 mm/11.3 inches
Vert.: 509.8 mm/20.1 inches
USB Port I/P: USB Specification Revision 2.0
Port: Upstream 1
Downstream 1
Power Supply AC 100-240 V ~ 50/60 Hz (DC 19 V 2.1 A)
AC Adapter Type ADP-40ED B, manufactured by DELTA ELECTRONICS
Power Maximun Operation: 27 W
Consumption Normal Operation: 22 W (Default setting)
Dimensions Landscape: 540.2 mm (W) x 401.3 - 511.3 mm (H) x 215 mm (D)
21.3 inches (W) x 15.8 - 20.1 inches (H) x 8.5 inches (D)
Portrait: 318.2 mm (W) x 547.2 - 627.3 mm (H) x 215 mm (D)
12.5 inches (W) x 21.5 - 24.7 inches (H) x 8.5 inches (D)
Height Adjustment: 110 mm/4.3 inches (Landscape condition)
80.1 mm/3.2 inches (Portrait condition)
Weight 4.2 kg (9.3 lbs)/Without stand: 2.8 kg (6.2 lbs)
Environmental Considerations
Operating Temperature: 5°C to 35°C / 41°F to 95°F
Humidity: 20% to 80%
Altitude: 0 to 6,562 Feet / 0 to 2,000 m
Storage Temperature: -10°C to 60°C / 14°F to 140°F
Humidity: 10% to 85%
Altitude: 0 to 40,000 Feet / 0 to 12,192 m
*1 Interpolated Resolutions: When resolutions are shown that are lower than the pixel count of the LCD module, text may appear different. This is
normal and necessary for all current flat panel technologies when displaying non-native resolutions full screen. In flat panel technologies, each dot on
the screen is actually one pixel, so to expand resolutions to full screen, an interpolation of the resolution must be done.
NOTE: Technical specifications are subject to change without notice.

NEC MultiSync EX231Wp Specifications

General

3D	No
Pixel pitch	0.27 x 0.27 mm
Aspect ratio	16:9
Response time	25 ms
Composite sync	Yes
Display diagonal	23 \
Video input impedance	75 Ω
Contrast ratio (dynamic)	-
Contrast ratio (typical)	3000:1
Display number of colors	16.78 million colors
Digital vertical frequency	56 - 75 Hz
Digital horizontal frequency	31.5 - 83 kHz
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
VGA (D-Sub) ports quantity	0
Intelligent mode	IPM
Certification	Energy Star 5.0 TCO 5.2 EPEAT Gold RoHS
Product color	Black
Height adjustment	110 mm
Panel mounting interface	100 x 100 mm
Power consumption (typical)	27 W
Power consumption (PowerSave)	0.37 W
Cables included	DVI, USB, VGA
Bundled software	NaViSet
Operating altitude	0 - 2000 m
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 85 %
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Bezel width (top)	16.4 mm
Bezel width (side)	14.6 mm
Depth (with stand)	215 mm
Height (with stand)	511.3 mm
Weight (with stand)	4200 g
Depth (without stand)	47.7 mm
Width (without stand)	540.2 mm
Height (without stand)	318.3 mm
Weight (without stand)	2800 g
