Specifications
11
Monitor MultiSync
®
P1250+
™
Notes
Specifications Monitor
Picture Tube Diagonal: 21 inch 90° deflection, 0.28 mm grille pitch,
Viewable Image Size: 19.6 inch medium short persistence phosphor, aperture
Radius: 1850 mm grille CRT, multi-layered, anti-static screen
coating, dark-tint screen, and OptiClear
®
screen surface.
Input Signal Video: ANALOG 0.7 Vp-p/75 Ohms
Sync: Separate sync. TTL Level
Horizontal sync. Positive/Negative
Vertical sync. Positive/Negative
Composite sync. (Positive/Negative) (TTL Level)
Sync on Green video (Positive) 0.7 Vp-p and sync.
(Negative) 0.3 Vp-p
Display Colors Analog input: Unlimited number of Colors Depends on display card used.
Synchronization Horizontal: 31 kHz to 110 kHz Automatically
Range Vertical: 55 Hz to 160 Hz Automatically
Resolutions Supported 640 x 480 @ 60 to 160 Hz
Some systems may not support
Resolution based on
horizontal and
800 x 600 @ 55 to 160 Hz
all modes listed.
vertical frequencies only
832 x 624 @ 55 to 160 Hz
1024 x 768 @ 55 to 137 Hz
1152 x 870 @ 55 to 120 Hz
1280 x 1024 @ 55 to 103 Hz ...................
NEC cites recommended resolution at
1600 x 1200 @ 55 to 88 Hz
85 Hz for optimal display performance
1800 x 1440 @ 55 to 73 Hz
Active Display Area Horizontal:
384 mm/15.1 inches Dependent upon signal timing used,
(Factory Setting) Vertical:
288 mm/11.3 inches and does not
include border area.
Active Display Area
398 mm/15.7 inches Dependent upon signal timing used,
(Full Scan)
299 mm/11.8 inches and does not
include border area.
Power Supply
AC 100 – 120 V/220 - 240 V@, 50/60 Hz
Current Rating 2.5A @ 100
–
120 V/1.1A@ 220-240 V
Dimensions
509 mm (W) x 519 mm (H) x 525 mm (D)
20.0 inches (W) x 20.4 inches (H) x 20.7 inches (D)
Weight 34.3 kg
75.6 lbs
Environmental Considerations
Operating Temperature: 10°C to +35°C
Humidity: 30% to 80%
Feet: 0 to 10,000 Feet
Storage Temperature: -20°C to +60°C
Humidity: 10% to 90%
Feet: 0 to 45,000 Feet
NOTE: Technical specifications are subject to change without notice.
