NEC MultiSync V404-T User Manual

English-61
English
c DisplayPort = 1.2/HDMI = MODE1
Sub picture
DisplayPort1 DisplayPort2 DVI HDMI1 HDMI2
VGA
(RGB)
VGA
(YPbPr)
Video OPTION MP
Connector
DisplayPort
IN1
DisplayPort
IN2
DVI-D
HDMI
IN1
HDMI
IN2
VGA (RGB,
YPbPr)
VIDEO
IN
Option board
slot (SLOT2
(DP))
Option board
slot (SLOT2
(HDMI))
-
Main picture
DisplayPort1 DisplayPort IN1 No No No No No No No No No No No
DisplayPort2 DisplayPort IN2 No No No No No No No No No No No
DVI DVI-D No No Yes No Yes Yes Yes No No No No
HDMI1 HDMI IN1 No No No Yes Yes Yes Yes No No No No
HDMI2 HDMI IN2 No No Yes Yes Yes Yes Yes Yes No Yes Yes
VGA (RGB)
VGA (RGB,
YPbPr)
No No Yes Yes Yes No No Yes No Yes Yes
VGA (YPbPr) No No Yes Yes Yes Yes Yes Yes No Yes Yes
VIDEO VIDEO IN No No No No Yes Yes Yes Yes No No No
OPTION
Option board slot
(SLOT2 (DP))
No No No No No No No No No No No
Option board slot
(SLOT2 (HDMI))
No No No No Yes Yes Yes No No No No
MP - No No No No Yes Yes Yes No No No Yes
d DisplayPort = 1.2/HDMI = MODE2
Sub picture
DisplayPort1 DisplayPort2 DVI HDMI1 HDMI2
VGA
(RGB)
VGA
(YPbPr)
Video OPTION MP
Connector
DisplayPort
IN1
DisplayPort
IN2
DVI-D
HDMI
IN1
HDMI
IN2
VGA (RGB,
YPbPr)
VIDEO
IN
Option board
slot (SLOT2
(DP))
Option board
slot (SLOT2
(HDMI))
-
Main picture
DisplayPort1 DisplayPort IN1 No No No No No No No No No No No
DisplayPort2 DisplayPort IN2 No No No No No No No No No No No
DVI DVI-D No No Yes No No Yes Yes No No No No
HDMI1 HDMI IN1 No No No No No No No No No No No
HDMI2 HDMI IN2 No No No No No No No No No No No
VGA (RGB)
VGA (RGB,
YPbPr)
No No Yes No No Yes No Yes No No Yes
VGA (YPbPr) No No Yes No No No Yes Yes No No Yes
VIDEO VIDEO IN No No No No No Yes Yes Yes No No No
OPTION
Option board slot
(SLOT2 (DP))
No No No No No No No No No No No
Option board slot
(SLOT2 (HDMI))
No No No No No No No No No No No
MP - No No No No No Yes Yes No No No Yes
Video out
Main picture
DisplayPort1 DisplayPort2 DVI HDMI1 HDMI2
VGA
(RGB)
VGA
(YPbPr)
Video OPTION MP
Connector
DisplayPort
IN1
DisplayPort
IN2
DVI-D
HDMI
IN1
HDMI
IN2
VGA (RGB,
YPbPr)
VIDEO
IN
Option board
slot (SLOT2
(DP))
Option board
slot (SLOT2
(HDMI))
-
DisplayPort Yes No No No No No No No Yes No No
When the monitor output a signal from the DisplayPort out, Please select input signal DisplayPort1 or OPTION.
This monitor’s signal output function is supporting contents which is protected by HDCP. In this case, up to 3 monitors are connectable.
When using an option, Please set SLOT2 CH SETTING to 1CH then set SLOT2 CH SELECT to DisplayPort (See page 44).
NOTE: To output a signal from the DisplayPort out, some Slot2 type options are only available which have DisplayPort signal out.
