NEC MultiSync V422 Control Guide

(26/71)
6.3. Operation Code (OP code) Table
Item OP
code
page
OP code Parameter Remarks
Backlight 00h 10h 0: dark
|
100(64h): bright
Contrast 00h 12h 0: low
|
100(64h): high
Sharpness 00h 8Ch 0: dull
|
24(18h): sharp
Brightness 00h 92h 0: dark
|
100(64h): bright
Hue 00h 90h 0: purplish
|
100(64h): greenish
Color 02h 1Fh 0: pale
|
100(64h): deep
Color Temperature 00h 54h 0:2600K
|
74(4Ah):10000K
100K/step
Color control 00h Red: 9Bh
Yellow: 9Ch
Green: 9Dh
Cyan: 9Eh
Blue: 9Fh
Magenta: A0h
0:
|
100(64h):(center)
|
200(C8h):
Gamma Correction 02h 68h Gamma
Table Selection
1: Native
 Gamma
4: Gamma=2.2
8: Gamma=2.4
7: S Gamma
5: DICOM SIM.
6: Programmable
Adaptive
Contrast
02h 8Dh 0: None
1: Off
2: Low
3: Middle
4: High
Noise
Reduction
02h 26h 0: Off
|
5: High
Page02-20
also works a
s
same.
Movie
Settings
Telecine 02h 23h 1: Off
2: Auto
Picture mode 02h 1Ah 1: sRGB
3: Hi-Bright
4: Standard
5: Cinema
6: ISF-Day
7: ISF-Night
11(0Bh): Ambient-1
12(0Ch): Ambient-2
sRGB:
PC mode only
Cinema:
A/V mode only
ISF-Day:
ISF-Night:
Each needs an
adjust
ment by
ISF.
Ambient
Brightness
Low
10h 33h 0: dark
|
100(64h): bright
Ambient
Ambient
Brightness
High
10h 34h 0: dark
|
100(64h): bright

NEC MultiSync V422 Specifications

General

Pixel pitch	0.48 x 0.48 mm
Response time	10 ms
Display diagonal	42 \
Display brightness	370 cd/m²
Vertical scan range	50 - 85 Hz
Horizontal scan range	31.5 - 91.1 kHz
Contrast ratio (dynamic)	-
Contrast ratio (typical)	1300:1
Display number of colors	16.78 million colors
Supported graphics resolutions	720 x 400, 832 x 624, 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 768 (WXGA), 1360 x 768 (WXGA), 1600 x 1200 (UXGA), 1920 x 1080 (HD 1080), 640 x 480 (VGA), 800 x 600 (SVGA)
3D	No
Separate H/V sync	Yes
Cable lock slot type	Kensington
USB 2.0 ports quantity	0
S-Video inputs quantity	1
Viewable size, vertical	523.3 mm
Viewable size, horizontal	930.2 mm
DVI-D ports quantity	2
Product color	Black
Product design	Digital signage flat panel
Bezel width (side)	44 mm
Bezel width (bottom)	43 mm
Panel mounting interface	300 x 300 mm
RMS rated power	10 W
Cables included	VGA
Remote control type	IR
Power consumption (standby)	2 W
Power consumption (typical)	155 W
Operating altitude	0 - 3000 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Package depth	206 mm
Package width	1142 mm
Package height	703 mm
Package weight	27000 g

Weight and Dimensions

Depth	105.6 mm
Width	1022.9 mm
Height	613.5 mm
Weight	22000 g
Depth (with stand)	330 mm
Height (with stand)	651.2 mm
Weight (with stand)	23800 g
