39
m When selecting “EDGE ALL”/”EDGE SEPA.”
FOCUS
- CORNER -
CRT - R -
SCREEN - BR -
+10%
1) Press and hold the CTL button then press any one of the
CURSOR buttons to select the position to be adjusted. (The
marker on the selected side will turn to a solid color.)
CTL + (Top) CTL + (Right)
CTL + (Bottom) CTL + (Left)
• To switch to Bottom from Top, press and hold CTL, then press
CURSOR twice.
• To switch to Top from Bottom, press and hold CTL, then press
CURSOR twice.
• To switch to Left from Right, press and hold CTL, then press
CURSOR twice.
• To switch to Right from Left, press and hold CTL, then press
CURSOR twice.
2) Use the CURSOR buttons to adjust the focus.
• Pressing the or button increases the control levels of the
edge focus. (The gauge mark in the scale moves to the right.)
• Pressing the or button decreases the control levels of the
edge focus. (The gauge mark in the scale moves to the left.)
3) To switch to the CENTER screen, use the CTL and CURSOR
buttons as follows:
• To switch to CENTER from Top, press and hold CTL, then
press CURSOR .
• To switch to CENTER from Bottom, press and hold CTL, then
press CURSOR .
• To switch to CENTER from Right, press and hold CTL, then
press CURSOR .
• To switch to CENTER from Left, press and hold CTL, then
press CURSOR .
m When selecting “CORNER”
• Press and hold the CTL button then press any one of the
CURSOR buttons to select the position to be adjusted. (The
marker on the selected side will turn to a solid color.)
CTL + ......
CTL + ......
CTL + ......
CTL + ......
• Use the CURSOR buttons to adjust the focus.
Pressing the or button increases the control levels of the
corner focus. (The guage mark in the scale moves to the
right.)
Pressing the or button decreases the control levels of the
corner focus. (The guage mark in the scale moves to the left.)
FOCUS
- EDGE SEPARATE -
CRT - R -
+10%
SCREEN -TOP-
TR (Top right)
BR (Bottom right )
TL (Top left )
BL (Bottom left)
ADJUSTMENT
To Next Page
