Specifications
Picture tube 27 inch Visual size; 29 inch CRT size (Diagonal), Type M68LLR696X02
108 degree deflection
Stripe trio pitch Ph 0.74 mm at center, Ph 0.90 mm at corner/Pv 0.64 mm
Invar mask, Medium-short persistence phosphor
Anti-static electricity coating
Optical filter coating
Dynamic focus
RGB Input Terminals
RGB 1,2 : Mini D-SUB 15pin
: Video : 0.7Vp-p/75 Ohms (Positive)
: Sync. : Separate Sync. TTL level
Horizontal Sync. (Positive/Negative)
Vertical Sync. (Positive/Negative)
: Composite Sync. TTL Level (Positive/Negative)
: Composite Sync. On Green Video 0.3Vp-p (Negative)
Video Input Terminals 1.0Vp-p, 75 Ohms unbalanced (RCA-Jack), Composite video signal, Sync-negative.
VIDEO 1/2 Y : 1.0Vp-p, 75 Ohms unbalanced, Sync-negative.
S-VIDEO (Video 1/2) C : 0.28Vp-p, 75 Ohms unbalanced, Color burst level.
Audio Input Terminals Left (Mono) : 0.5 Vrms, high impedance (Pin-Jack)
VIDEO 1, 2 / RGB Right : 0.5Vrms, high impedance (Pin-Jack)
Monitor Output Terminal Left : 0.5 ± 0.1 Vrms, less than 22 K Ohms (Pin-Jack)
Right : 0.5 ± 0.1 Vrms, less than 22 K Ohms (Pin-Jack)
SOUND Output
Internal 5W+5W (THD 10%) at 8 Ohm
Speaker Oval type 9 X 5.0 cm
8 Ohm, 2pcs.
Display Colors Analog Input: Unlimited colors
Synchronization Range Horizontal: XV29 Plus; 15.7/31 KHz to 50 KH (Automatically)
Vertical:50 Hz to 90 Hz (Automatically)
