15
POWER MANAGEMENT FUNCTION
The following is a description of these power states and the power consumed in each state:
MODE LED H-SYNC V-SYNC VIDEO POWER CONSUMPTION
on green Pulse Pulse Active Pw(maximum)
power saving yellow No pulse Pulse Not used <30W
power saving yellow Pulse No pulse Not used <30W
power saving yellow No pulse No pulse Not used <30W
Note: The power management function requires TTL horizontal and vertical sync.
Power saving is invalid if display is in AV mode.
