6
6. Horizontal size 520mm +/- 5 min (for mode 1-6)
Vertical size 388mm +/- 5 min (for mode 1-6)
7. User controls Power, Brightness, contrast, V-Size, Mute, V-position,
H-Size, Tint, H-Position, Degauss, Pincushion, Rotation,
Bass Treble, Balance, Color, Sharpness, Volume, Woofer,
audio FIX/VAR, Recall, Input.
8. Operating temperature 0°C to 40°C
9. Unit dimension (with base): W (742mm) X H (575mm) x D (512mm) – (29.2” x 22.6” x 20.2”)
packaging dimension: W (911mm) x H (659mm) x D (711 mm) – (35.9” x 25.9” x 28”)
10. Net weight of unit: 51 Kg/l 12.4lbs
11. The table below is required timings and technical description for the 27” tube
(H=520mm, V=388mm standard size)
Mode No 1 2 3 4 5 6
Resolution & Refresh 640×640 640×480 720×400 640×480 800×600 800×600
R a t e 60 72 70 66.6 60.317 56.25 Hz
Pixel timing +/- 5% 39.722 31.746 35.311 33.06 25 27.8 Nsec
Hor. visible 640 640 720 640 800 800 dots
Hor. total 800 832 900 864 1056 1024 dots
Hor. front porch 16 16 18 64 40 24 dots
Hor. sync 96 40 108 64 128 72 dots
Hor. back porch 48 136 54 96 88 128 dots
Hor. blanking time 160 192 180 224 256 224 dots
Ver. Visible 480 480 400 480 600 600 lines
Ver. Total 525 520 449 525 628 625 lines
Ver. Front porch 10 1 12 3 1 1 lines
Ver. Sync 2 3 2 3 4 2 lines
Ver. Back porch 33 36 35 39 23 22 lines
Ver. Blanking time 45 40 49 45 28 25 lines
Hor. Frequency 31.469 37.681 31.467 35 37.879 35.156 KHz
Vor. Frequency 59.940 72.809 70.082 66.667 60.317 56.250 Hz
Ver. Sync polarity – – + – + + TTL
Hor. Sync polarity – – – + + + TTL
Bandwidth 25.2 31.2 28.3 30.204 40 35.97 MHz
