3.14 [ 030-15. OTHER ADJUST ]
Adjusts the various gains.
Command
03h 10h 00h 00h 05h <DATA01> - <DATA05> <CKS>
Data part
Item Description
DATA01
DATA02
DATA01 DATA02 Adjustment target
96h FFh LAMP ADJUST / LIGHT ADJUST
DATA03 Adjustment mode
00h Specify an absolute value
01h Specify a relative value
DATA04 Adjustment value (low-order 8 bits)
DATA05 Adjustment value (high-order 8 bits)
