NEC NP-V300W - Diagrams and Distance Charts; Ceiling Mounted

NEC Display Solutions of America, Inc.
V260/V260X/V300X/V300W Installation Guide
Ceiling Mounted and Desktop Rev 1.0
www.necdisplay.com V260/V260X/ V300X/V300W Page 4 of 8
Diagrams and Distance Charts
The following shows the proper relative positions of the projector and screen. Refer to the table to determine the position of
installation.
Distances are in inches. For millimeters multiply by 25.4.
Lens Offset From
Mount Pipe
B
C
Lens Ctr
Screen Ctr
Throw Distance
Screen Bottom
2.73"
C
Throw Distance
Screen Top
3.84"
9.11"
D
B
Lens Ctr
Screen Ctr
D
3.78"
Ceiling Mounted
Desktop
