16
AUDIO
IN
AUDIO OUT
PHONE
MONITOR OUT
COMPUTER 1 IN (or COMPUTER 2 IN / COMPONENT IN)
2. Installation and Connections
Connecting an External Monitor
You can connect a separate, external monitor to your projector to simultaneously view on a monitor the RGB analog
or component image you're projecting.
NOTE:
• Daisy chain connection is not possible.
• The MONITOR OUT connector will output no video signal (Digital signal) from the COMPUTER 3 IN connector.
• When audio equipment is connected, the projector speaker is disabled.
VGA signal cable
VGA signal cable (supplied)
Audio cable (not supplied)
Audio cable (not supplied)
