Server
Hub
LAN cable (not supplied)
2. Installation and Connections
(B) Example of wireless LAN connection
(Network Type
→
Infrastructure)
To make connection with a wired LAN or wireless LAN via a wireless access point, you need to select the Infra-
structure mode.
From the menu, select [SETUP]
→
[INSTALLATION]
→
[NETWORK SETTINGS]
→
[WIRELESS]
→
[ADVANCED]
→
[CONNECTION]
→
[NETWORK TYPE]
→
[INFRASTRUCTURE].
PC with wireless
LAN card inserted
PC with built-in wireless
LAN function
To Next Page
