6
1. Introduction
Terminals
(→ page 9)
Rear
Remote Sensor (located on the
front and the rear)
(→ page 12)
AC IN Terminal
Connect the supplied power cord’s
three-pin plug here, and plug the
other end into an active wall outlet.
(→ page 14)
* This security slot supports the MicroSaver
®
Security System.
Built-in Security Slot ( )*
Cable cover connection
(right and left)
Screw holes and grooves for the
optional cable cover
(→ page 7)
Intake vent
(→ page xi, 148)
Security Bar
Attach an anti-theft device.
The security bar accepts security
wires or chains up to 0.18 inch/4.6
mm in diameter.
To Next Page
