6.8 Alarm Items
Alarms outputs are available to connect to RL1 to RL11.
Alarm output connection to RL( ) is changeable by LCT.
Summarized external alarms (Form-C)Event
Connector “ALM” Connector “AUX/ALM”
RL1 RL2 RL3 RL4 RL5 RL6 RL7 RL8 RL9 RL10 RL11
MAINT • - - - - - - - - - -
PS ALM - • - - - - - - - - -
CPU ALM - - • - - - - - - - -
ODU ALM1 - - - •
¢ ¢ ¢ ¢ ¢ ¢ ¢
ODU ALM2 - - - •
¢ ¢ ¢ ¢ ¢ ¢ ¢
CBL ALM1 - - -
¢ ¢ ¢ ¢ ¢ ¢ ¢ ¢
CBL ALM2 - - -
¢ ¢ ¢ ¢ ¢ ¢ ¢ ¢
TX PWR ALM1 - - -
¢ ¢ ¢ ¢ ¢ ¢ ¢ ¢
TX PWR ALM2 - - -
¢ ¢ ¢ ¢ ¢ ¢ ¢ ¢
TX IN ALM1 - - -
¢ ¢ ¢ ¢ ¢ ¢ ¢ ¢
TX IN ALM2 - - -
¢ ¢ ¢ ¢ ¢ ¢ ¢ ¢
RX IN ALM1 - - -
¢ ¢ ¢ ¢ ¢ ¢ ¢ ¢
RX IN ALM2 - - -
¢ ¢ ¢ ¢ ¢ ¢ ¢ ¢
APC ALM1 - - -
¢ ¢ ¢ ¢ ¢ ¢ ¢ ¢
APC ALM2 - - -
¢ ¢ ¢ ¢ ¢ ¢ ¢ ¢
IDU ALM1 - - -
¢
•
¢ ¢ ¢ ¢ ¢ ¢
IDU ALM2 - - -
¢
•
¢ ¢ ¢ ¢ ¢ ¢
MOD ALM1 - - -
¢ ¢ ¢ ¢ ¢ ¢ ¢ ¢
MOD ALM2 - - -
¢ ¢ ¢ ¢ ¢ ¢ ¢ ¢
DEM ALM1 - - -
¢ ¢ ¢ ¢ ¢ ¢ ¢ ¢
DEM ALM2 - - -
¢ ¢ ¢ ¢ ¢ ¢ ¢ ¢
Sub INTFC - - -
¢ ¢ ¢ ¢ ¢ ¢ ¢ ¢
MAIN INTFC - - -
¢ ¢ ¢ ¢ ¢ ¢ ¢ ¢
BER ALM1 - - -
¢ ¢
•
¢ ¢ ¢ ¢ ¢
BER ALM2 - - -
¢ ¢
•
¢ ¢ ¢ ¢ ¢
STM-1 LOS - - -
¢ ¢ ¢
•
¢ ¢ ¢ ¢
HK-OUT1 - - - - - - - - - - •
HK-OUT2 - - - - - - - - - • -
HK-OUT3 - - - - - - - - • - -
HK-OUT4 - - - - - - - • - - -
Note:
•
marks are set at factory.
¢
marks are range for selection.
