SL1100 Installation Instructions
1-888-632-3794 • info@necsl1100distributors.com
1
Connecting to an SL1100 that is NOT on a Network
and DOES NOT Have a VoIP Card:
Requirements:
Two (2) Ethernet Cables. (We’ve include one Free Ethernet Cable with this purchase)
Windows XP, Vista or Windows 7
PC PRO System Administrator Software (Available in the Downloads Section on necsl1100distributors.com)
One router (We recommend the EnGenius ESR300 Router)
Part 1: Assigning an IP Address
1. Connect the first Ethernet Cable from your computer (must be a PC, not a MAC) to a LAN port on your
Router (NOT the WAN Port).
2. Connect the second Ethernet Cable from the Ethernet Port on the CPU Card of the SL1100 to another
LAN port on the router. (See the diagram of the SL1100’s Ethernet Port below)
To Next Page
