UNIVERGE SV8300 Features and Specifications Manual (ISDN/Q-SIG)
Page 4
NWA-033632-001, Issue 1
Advice of Charge - Display
■
Conditions for ISDN-AOC-E information output to SMDR
The call charge and the call unit can be output at the same time. The conditions of output of call unit and call
charge in SMDR are as follows.
1. SMDR-RS (Output conditions of both 2400IMS standard format and extended format are the same.)
a. Up to four digits are output for a call unit. If it exceeds four digits, 9999 is output. An empty digit is
output as 0.
b. Up to six digits are output for a call charge. If it exceeds six digits, it is output as 999999. An empty
digit is expressed as a space.
2. SMDR-LAN
Same as SMDR-RS
3. Output example
When the call unit is 16 and the call charge is 16 Euro 32 cents
Output Call Unit Call Charge
SMDR-RS/LAN 0016
∆∆
1632
*1:
∆
indicates a space.
