NEC V191W User Manual

English
English-3
Contents
Your new NEC LCD monitor box* should contain the following:
• LCD monitor with tilt base
• Power Cord
•Video Signal Cable
• Setup Manual
• CD-ROM (only EU)
• Base Stand
• Stand Neck
Quick Start
To attach the Neck/Base to the LCD monitor.
1. Insert the front of the Stand neck into the holes in the front of Base stand.
The snapping tabs on the Base stand should fit into the hole on the Stand neck
(Figure S.1).
2. Insert the front of the Stand neck into the holes in the LCD monitor.
The snapping tabs on the LCD monitor should fit into the hole on the Stand neck
(Figure S.1).
To attach the LCD monitor to your system, follow these instructions:
1. Turn off the power to your computer.
2. For the PC with Analog output: Connect the 15-pin mini D-SUB signal cable
connected with the monitor to the connector of the display card in your system
(Figure A.1). Tighten all screws.
For the Mac: Connect the Macintosh cable adapter (not included) to the computer.
Attach the 15-pin mini D-SUB signal cable to the Macintosh cable adapter
(Figure A.2). Tighten all screws.
NOTE: Some Macintosh systems do not require a Macintosh cable adapter.
Setup Manual
Power Cord
(Type of power cord included will
depend on the where the LCD
monitor is to be shipped)
Video Signal Cable LCD monitor
(Stand not connected)
CD-ROM
(only EU)
* Remember to save your original box and packing material to transport or ship the monitor.
Figure A.2
Macintosh Cable Adapter
(not included)
Figure A.1
Figure S.1
LCD monitor
Base stand
Stand neck
Setup
Manual
