Necta Colibri - Wiring Diagrams

© by NECTA VENDING SOLUTIONS SpA 01-2003 197 00
35
INITIALS DESCRIPTION
WIRING DIAGRAM LEGEND
INITIALS DESCRIPTION
BDV BDV COIN MECH CONNECTOR
CM1-2 COFFEE UNIT MOTOR CAM
CMSB CUP RELEASE MOTOR CAM
CV VOLUMETRIC COUNTER
E1-... INSTANT SOLENOID VALVE
EEA WATER INLET SOLENOID VALVE
ER COFFEE DISPENSER SOLENOID VALVE
ESC COFFEE RELEASE MAGNET
EX EXECUTIVE COIN MECH CONNECTOR
FA RADIO INTERFERENCE SUPPRESSOR
ID COFFEE DOSE SWITCH
IMSP STIRRER RELEASE MICRO-SWITCH
IP DOOR SWITCH
IPF WASTE CONTAINER OVERFLOW SWITCH
IVA EMPTY BOILER MICRO-SWITCH
IVB EMPTY CUP DISPENSER MICRO SWITCH
KC1-.. COFFEE BOILER CUTOUT
KS1-.. SAFETY CUTOUT
LCD LIQUID CRYSTAL DISPLAY
M COFFEE UNIT MOTOR
MAC GRINDER
MD1-.. DOSER UNIT - INSTANT
MDB MDB COIN MECH CONNECTOR
MDTE DOSER UNIT - TEA
MDZ DOSER UNIT - SUGAR
MF1-.. WHIPPER MOTORS
MSB CUP RELEASE MOTOR
MSCB CUP CONTAINER SHIFT MOTOR
MSP STIRRER RELEASE MOTOR
NTC TEMPERATURE PROBE
PM PUMP
RCC COFFEE BOILER HEATING ELEMENT
RIS COFFEE UNIT HEATER
RS232 SERIAL PORT
SM CONTROL BOARD
SP PUSH-BUTTON BOARD
TR TRANSFORMER
TR1 TRANSFORMER 230 V 24 V
TX.... DELAYED FUSE (X=COURRENT)
VAR VARISTOR
VENT FAN
