Nectar Hex - Cleaning Guide: Deep Clean; Dismantling the Cooling Unit; Cleaning Filters (Method 1); Replacing Filters (Method 2)

14 15 16 17 18
Dismantle the cooling unit
1. Rotate and pull the mouthpiece off the cooling unit.
2. Detach the resin trap by pulling off.
3. Dismantle the resin trap into its 3 separate pieces.
04
Method 1: Cleaning the filters
05
Use a brush soaked in ISO to disinfect and clean
any excess residue from the Resin Trap, its gauze
and the rubber holder. Now rinse off each part with
lukewarm water and then dry using a clean cloth. Put
your device back together, sterilise and use.
Method 2: Replacing the filters
06
The resin trap collects unwanted residue so you can
conveniently replace the entire section or just parts of
it. When replacing parts, simply disassemble your
device and reassemble it with the new parts.
Note: Isopropyl alcohol deforms rubber. Do NOT soak rubber parts for more than 30s.
Cleaning: Deep Clean
Perform a deep clean once every 20 sessions (Steps 1 to 6).
