Remote Controller
Main Cable
Instruction Manual
Power Cable
Headrest Shroud (Only For 5", 5.8")
Trim Ring Shroud (Only For 5", 5.8")
Interconnection Box , AD- 6865
Dash Mount , S2 (Optional - for 5",5.8")
Item Description
Precautions :
1. This unit should be install by qualified technicians
or service personnel.
2. This product is designed to operate with a 12 volt,
negative ground battery system.
3. Disconnect the ground wire from the battery terminal before connecting
the electrical system.
4. Refer to the electrical connection diagram to avoid wrong connection of
the electrical system. Always use authorized service center for service
assistance.
5. Use proper insulation material to prevent short - circuiting of the supply
system.
6. Tighten all loose wires after installation.
7. Refer to this operating instruction for system upgrade and operation.
10
5
6
Accessories Supplied :
1
3
4
8
7
2
Item
1
1
Quantity
1
1
1
1
1
1
