03
Interconnect Cable
Assembly , Monitor
Red Wire : ACC
Black Wire : Ground
Blue Wire : 12 Vdc (1A)
Output
Interconnection
Box AD-6865
Video Out
Video source 2
(Input)
Yellow Wire : Battery (+)
Wiring System :
Electrical Connections (General)
Video source 1
(Input)
