Nederman FilterCart Original User Manual

FilterCart Original
13
EN
Table 3-1: Technical data
Capacity 750–1050 m
3
/h (430–620 cfm)
Filtrationeciency,mainlter >99%averageweightltrationeciency
Filtrationeciency,HEPAlter > 99.97 % DOP 0.3 µm
Filterarea,mainlter 35 m
2
(377 ft
2
)
Filterarea,HEPAlter 7.5 m
2
(81 ft
2
)
Motor power
0.75kW(1hp)
Voltage * 110/120/2390/240
Phase * 1 ~
Frequency * 50/60 Hz
Spot light
20W,24V
Transformer 24 V secondary
Weight:
• 71 kg (156 lb) with 2 m arm
• 73 kg (161 lb) with 3 m arm
Temperature, max. ambient temp. 40 °C (104 °F)
Temperature,max.airowtemp. 60 °C (140 °F)
Noise level 73 dB(A) ISO 11203
Material recycling
90weight-%withoutltercartridge
* See type label.
See wiring diagram, Figure 2, for electrical details.
E1: 20 W, 24 V.
F1: Start/stop overload protector.
F2: 1 AT, 5 x 20 mm.
T1: Transformer.
M1: 0.75 kW.
Black: Black wire.
Brown: Brown wire.
Blue: Blue wire.
4 Hood mounting instruction
The Fume Extractor arm is already tted. The hood must be tted according to
the Figure 3, items A–D.
A. Insert the hood into the swiveling arm, and fasten together.
B. Adjust the swiveling arm to the correct tension.
C. Ensure that the swiveling arm has the correct tension and can be easiliy
positioned.
D. Fasten the blue hose into the hood and secure it using the tightening ring.
