Quick guide to the EcHo Plus
Buttons, indicators and connectors are available on the front and rear panels. These are shown
below:
Front:
Number: Description
1 Push buttons for controlling the AV setup
2 Red LED lights for indication of AV setup status
3 Front panel glass with label for button description
4 Mini USB for programming (behind front glass)
Rear:
Number: Description
1
RS-232 port, Bi-directional
2
RS-232 or IR port, Uni-directional
3 NEB bus port
4 Input/Output connector
5 12 VDC power input
6 RJ-45 Network (LAN) connector
