en Rails
20
Finishing
As soon as the cleaning aid has finished, an audible
signal sounds and the appliance ends the operation
automatically.
As soon as you open the appliance door, the interior
lighting is switched on so that you can finish cleaning
the cooking compartment more easily. The remaining
water in the cooking compartment must be removed
promptly. Do not leave the remaining water in the
cooking compartment for a long time (e.g. overnight).
The appliance must not be operated when the cooking
compartment is still wet or damp.
Final cleaning
1. Open the appliance door and remove the remaining
water with an absorbent sponge cloth.
2. Clean the smooth surfaces in the cooking
compartment with a dish cloth or a soft brush.
Stubborn residues can be removed using a stainless
steel scouring pad.
3. Remove limescale with a cloth soaked in vinegar.
Then wipe with clean water and rub dry with a soft
cloth (including under the door seal).
4. Use the # touch button to switch off the appliance.
5. Leave the appliance door ajar in the locking position
(approx. 30°) for approx. 1 hour to allow the enamel
surfaces in the cooking compartment to dry.
Alternatively, you can also run the rapid drying
function for the cooking compartment.
Running the rapid drying function for the cooking
compartment
1. After the cleaning aid process has finished, leave the
appliance door ajar in the locking position (approx.
30°).
2. Touch the # touch button.
3. Start CircoTherm hot air at 50 °C.
4. After 5 minutes, switch off the appliance and close
the appliance door.
Removing heavy deposits of dirt
You have several options for removing particularly
stubborn deposits of dirt.
■ Leave the soapy water to work for some time before
starting the cleaning aid.
■ Rub soapy water onto the dirt on the smooth
surfaces before starting the cleaning aid.
■ Repeat the cleaning aid once the cooking
compartment has cooled down.
pRails
Rails With good care and cleaning, your appliance will retain
its appearance and remain fully functional for a long
time to come. This will tell you how to remove the
shelves and clean them.
Detaching and refitting the rails
:Warning
Risk of burns!
The rails become very hot. Never touch the hot rails.
Always allow the appliance to cool down. Keep children
away from the appliance.
Detaching the rails
1. Lift the rail slightly at the front ‚ and detach it ƒ
(figure !).
2. Then pull the whole rail towards you and take it out
(figure ").
Clean the rails with cleaning agent and a sponge. For
stubborn deposits of dirt, use a brush.
Attaching the rails
The rails only fit on the right or the left side. For both
rails, ensure that the retaining bracket is at the front.
1. First, insert the rail in the middle of the rear socket ‚,
until the rail rests against the cooking compartment
wall, and push it back ƒ (figure !).
2. Then insert the rail into the front socket „, until the
rail also rests against the cooking compartment wall
here, and press it downwards … (figure ").
2
D
E
1
2
F
G
1
D
E

NEFF B47CR32N0B Specifications

General

Current	16 A
Connected load	3450 W
Power plug type	No plug
AC input voltage	220 - 240 V
Energy efficiency scale	A+++ to D
Energy efficiency index (EEI)	81.2
Energy consumption (conventional)	0.87 kWh
Energy consumption (forced convection)	0.69 kWh
Oven size	Medium
Oven type	Electric
Cleaning type	Catalytic (full) + Steam
Self-cleaning	-
Number of ovens	1
Total oven power	- W
Keep warm function	No
Cleaning technology	Hydrolytic
Oven thermostat range	40 - 200 °C
Pizza making function	Yes
Number of shelf positions	4
Total oven(s) interior capacity	71 L
Clock type	Electronic
Timer type	Digital
Door hinge	down
Cord length	1.2 m
Display type	TFT
Certification	CE, VDE
Door material	Glass
Product color	Stainless steel
Display diagonal	2.5 \
Appliance placement	Built-in
Door temperature (max)	40 °C
Effective tray surface area	1290 cm²
Lamp type	Halogen
Bread & dough making programs	Dough
Package depth	660 mm
Package width	690 mm
Package height	675 mm

Weight and Dimensions

Depth	548 mm
Width	596 mm
Height	595 mm
Weight	36424 g
Depth with door open	635 mm
Installation compartment depth	550 mm
Installation compartment width	568 mm
Interior dimensions (W x D x H)	480 x 415 x 357 mm
Installation compartment width (min)	560 mm
Installation compartment height (min)	585 mm
