Appliance door en
33
20.3 Removing the door panes
To facilitate cleaning, you can remove the door pane.
WARNING‒Risk of injury!
Components inside the appliance door may have sharp
edges.
▶ Wear protective gloves.
Requirements
¡ Have a screwdriver ready.
¡ The appliance door is detached.
1.
Lay the appliance door with the front side facing
down on a flat surface that is soft and clean.
2.
Undo and remove the left- and right-hand screws on
the appliance door .
3.
Carefully lift the inner pane upwards at an angle and
remove it in the direction of the arrow .
4.
Slide the screwdriver in between the metal tab
and the plastic.
5.
Use the screwdriver to lift the reflector until it
disengages, then lift it up and pull it out .
6.
Remove the second reflector in the same way as
the first.
7.
Push down on the intermediate pane lightly around
, and carefully lift the retainer until you are able
to pull it out.
8.
Lift the intermediate pane from below and remove
it in the direction of the arrow .
9.
WARNING‒Risk of injury!
Scratched glass in the appliance door may develop
into a crack.
▶ Do not use any harsh or abrasive cleaners or
sharp metal scrapers to clean the glass on the
oven door, as they may scratch the surface.
ATTENTION!
Damage to the lighting.
▶ Do not clean or touch the LEDs . The LEDs
are located on the right- and left-hand side in the
appliance door.
Clean the door panes and reflectors on both sides
with glass cleaner and a soft cloth.
10.
Dry the door panes and refit them.
20.4 Fitting the door panes
WARNING‒Risk of injury!
If a door pane or appliance door has not been installed
correctly, this is dangerous.
▶ Make sure that all of the door panes and the appli-
ance door have been correctly fitted before you
switch the appliance back on again.
