en Shelf supports
22
1.
Push on the tab marked PUSH behind the rail, and
push the rail to the rear.
2.
Keep the PUSH tab pushed back and swing the
rail outwards .
3.
Pull the rail out towards the front until the retainer at
the back unhooks.
4.
Remove the pull-out rail.
5.
Clean the pull-out rail.
→"Cleaning products", Page17
17.4 Attaching the pull-out rail
Note:The pull-out rails only fit on the right or left. Make
sure when you fit them that you can pull them out to-
wards the front.
1.
Insert the pull-out rail between the two bars.
2.
Push the retainer in between the lower and the
upper bar.
3.
Keep the PUSH tab pushed in and swing the pull-
out rail inwards until the front retainer is located
between the two bars .
‒ Release the PUSH tab.
a The retainer clicks into place.
