en Familiarising yourself with your appliance
6
4
Heating-up control
→"Heating-up control", Page8
5
Temperature selector
Use the temperature selector to set the temper-
ature for the type of heating or select the set-
ting for other functions. You can turn the tem-
perature selector clockwise from the "Off" posi-
tion, until it offers resistance.
→"Temperature and setting levels", Page7
6
Display
→"Display", Page6
7
Top oven
Controls for the top oven
8
Function selector
You can turn the function selector clockwise or
anti-clockwise from the zero setting.
→"Types of heating", Page6 →"Functions",
Page7
9
Heating-up control
→"Heating-up control", Page8
10
Temperature selector
Use the temperature selector to set the temper-
ature for the type of heating or select the set-
ting for other functions. You can turn the tem-
perature selector clockwise from the "Off" posi-
tion, until it offers resistance.
→"Temperature and setting levels", Page7
Note:Depending on the appliance type, the control
knobs can be pushed in. To click it in or out, push the
control knob in when it is in the off position.
4.2 Buttons
The buttons are touch-sensitive surfaces. Press the corresponding button to select a function.
Symbol Name Use
Time-setting options Sets the time, timer, cooking time or end time
→"Time-setting options", Page11
Left arrow Decreases the adjustment values
Right arrow Increases the adjustment values
4.3 Display
The display shows the current settings, options or relevant information.
The red bar above or below a symbol indicates which value is active or can be changed.
Symbol Name Use
Childproof lock activ-
ated
The childproof lock is activated
→"Childproof lock", Page12
Heating-up
indicator ⁠
Appliance is heating
→"Heating-up control", Page8
4.4 Types of heating
Here you can find an overview of the types of heating.
You can find recommendations on using the types of
heating.
Use the function selector to set the types of heating.
Main oven ⁠
Symbol Type of heating What it's used for/how it works
CircoTherm hot air Bake and roast on one or more levels.
The fan distributes the heat from the ring-shaped heating element in the back
wall evenly around the cooking compartment.
CircoTherm gentle Cook selected dishes gently on one level without preheating.
The fan distributes the heat from the ring-shaped heating element in the back
wall evenly around the cooking compartment. The food is cooked in phases us-
ing residual heat.
Select a temperature of between 120°C and 230°C.
Always keep the appliance door closed when cooking.
This type of heating is used to determine the energy consumption in air recircu-
lation mode and the energy efficiency class.

NEFF U1ACE2HG0B Specifications

General

Oven size	Medium
Oven type	Electric
Number of ovens	2
Total oven power	- W
Microwave cooking	No
Cleaning technology	EasyClean
Oven thermostat range	50 - 275 °C
Top and bottom heating	Yes
Number of shelf positions	4
Total oven(s) interior capacity	71 L
Current	32 A
Connected load	5900 W
Power plug type	No plug
AC input voltage	220-240 V
AC input frequency	50 Hz
Power connection type	Hard-wired
Energy efficiency scale	A+++ to D
Energy efficiency index (EEI)	95.3
Oven 2 energy efficiency class	B
Energy consumption (conventional)	1.02 kWh
Energy consumption (forced convection)	0.81 kWh
Oven 2 energy consumption (forced convection)	0.83 kWh
Oven 2 size	Small
Oven 2 net capacity	34 L
Oven 2 thermostat range	50 - 270 °C
Door hinge	down
Control type	Rotary, Touch
Display type	LCD
Handle color	Black
Door material	Glass
Product color	Graphite
Number of grids	3
Control position	Front
Interior material	Enamel
Oven door opening	Drop down opening
Appliance placement	Built-in
Number of baking trays	1
Clock type	Electronic
Timer type	Digital
Lamp type	Halogen
Lamps quantity	1 lamp(s)
Package depth	660 mm
Package width	690 mm
Package height	960 mm

Weight and Dimensions

Depth	550 mm
Width	594 mm
Height	888 mm
Weight	51000 g
Installation compartment width	568 mm
Installation compartment width (min)	560 mm
Installation compartment height (min)	875 mm
