3.3 Connection between NEMAG Rope Pear Sockets and
NEMAG Quick Release Links
A NEMAG Rope Pear Socket can be connected with a NEMAG Quick Release Link of the same size, or to a NEMAG Quick
Release Link of a different size as shown in the table below. The example below shows how you can find the correct size Quick
Release Link and Rope Pear Socket. An additional safety factor can be included.
Given:
• Steel wire rope with a diameter of 26 mm
• Safe working load of the steel wire rope: 10,000 kg
1. According to section 3.1 select NEMAG Rope Pear Socket no. 1026
2. Then, according section 3.1 and the table below, NEMAG Quick Release Link no.10 is possible
NEMAG Quick Release Link
size 4 5 6 7 8 9 10 11 12 13 14 15 17
NEMAG Rope Pear Socket
2
3
4
5
6
7
8
9
10
11
12
13
14
15
17
