NEMO GRABO | Operator’s manual
Battery charger
Charging output voltage
16.8V rated; 8 - 12V under load
Charging output current
200 - 400mA under load, 1.4A max
Charging input
100 - 240V AC; 50/60 Hz; 1.5A max.
Rated power
23.52W
Operating temperature
0°C … +40°C/+32°F ... +105°F
Storage temperature
-20°C ... +85°C/-4°F to +185°F
Working conditions
Indoor use only; not waterproof (IP0)
NEMO GRABO® lifting capacity
NOTICE: The NemoGRABO® was tested up to 240kg (530lbs) at maximum lifting force under
ideal conditions. However, this gure is the breaking point under optimal lab testing conditions
and must never be reached in real-world applications!
Local regulations require dierent safety margins to be used and the ocial tool Working Load
Limit (WLL) is set to 120kg (265lbs) based on a 2:1 ratio on a non-porous surface. The Working
Load Limit of 120kg (265lbs) is one-half of the tested maximum lifting force under ideal
conditions (240kg/530lbs) and should be adhered to when working in countries where the
2:1 safety margin applies, regardless of the fact that the chart below shows a maximum lifting
force of 170kg (375lbs). In no case should the NemoGRABO® be used to lift more than 170kg
(375lbs). Use the chart below to estimate safe lifting values:
WLL: 120kg (265lbs) on non-porous surfaces
IMPORTANT: The lifting force is highly dependent on the lifted surface and factors such as
temperature, altitude (ambient pressure), and other factors.
Always check the pressure displayed on the NemoGRABO® Pressure gauge Ⓖ and do not rely
solely on the estimated maximum lifting forces chart when lifting dierent materials since
dierent factors related to your specic application may reduce lifting capabilities of the tool.
Vertical lifting of non-porous materials (-0.8 bar)
0 (kg)
0 (lbs)
120 (kg)
265 (lbs)
170 (kg)
375 (lbs)
SAFE LIFTING CAUTION DANGER!
