3. Installation
3.3 How to do mounting installation.
Step one: Installation the clamp onto the omega bracket;
3.1 The device could be either put on a solid and even Sur-
face, or mounted upside down or sideways like le picture.
3.2 The mounting place must be suicient stable and be
able to support a weight of 10 times of the unit’s weight.
When the xture is hanged, always additionally secure the
device with the safety chain, fasten the safety rope at a
suitable position so that the maximum fall of the projector
will be 20 cm.
Step two: Install the clamp and bracket on the bottom of
panel, fasten the quick-locks;
Step three: Install the whole device onto appropriate truss
and fasten the clamps, tight the safety rope with the truss
or other xing point at a suitable position that drop down
distance not exceed 20 cm.
BOMBER
ENGLISH VERSION
p. 7
