5.
There are 10 stacker positions available. Select the
one that best matches the size of the folded document.
Press “ ” buttons to select the correct position
# P0 - P9. Press the “ ” button to enter selection and
advance to the test screen.
Stacker Wheel Positions:
P0 Folded size to: 3.75”
P1 Folded size to: 4.00”
P2 Folded size to: 4.43”
P3 Folded size to: 4.87”
P4 Folded size to: 5.30”
P5 Folded size to: 5.73”
P6 Folded size to: 6.16”
P7 Folded size to: 6.60”
P8 Folded size to: 7.03”
P9 Folded size to: 7.46” and greater
4.
Press the “1x” button to ensure the proper fold and
stacker positions have been entered. If the folds and
stacker position are correct press the “ ” button to
save. If the folds or stacker wheels need to be adjusted
press the “ ” button to edit.
PF-90 CUSTOM FOLDS SETUP, cont.
12
© 2009 Neopost USA Inc. All rights reserved.
