Example 1: “Z” Fold
1. Measure the length of panel “A” + “B”, enter this number as the
upper fold table measurement.
2. Measure the length of panel “B”, enter this number as the lower
fold table measurment.
Example 2: “C” Fold
1. Measure the length of panel “A”, enter this number as the upper
fold table measurement.
2. Measure the length of panel “B”, enter this number as the lower
fold table measurement.
Measuring Fold Lengths
Panel A
Panel B
Panel A
Panel B
Use the examples below to help determine the fold lengths for custom fold settings.
13
© 2009 Neopost USA Inc. All rights reserved.
