Annex A: Control Apps
Refer to Pressure & Applications – Menu (1 of 6) on page 8 for more information. The available Control Apps vary according to the
model.
Description
CL
(cool only)
CLHt
(cool/heat)
CHrH
(cool/heat/reheat)
CO
2
(CO
2
)
ITOS
(ITOS)
FPbo
(fan powered ON)
FPb
A
(fan powered Auto)
Min. Setpoint 20°C (68°F) 20°C (68°F) 20°C (68°F) 20°C (68°F) 15°C (59°F) 15°C (59°F) 15°C (59°F)
Max. Setpoint 28°C (82°F) 28°C (82°F) 28°C (82°F) 28°C (82°F) 30°C (86°F) 30°C (86°F) 30°C (86°F)
Changeover Setpnt 24°C (75°F) 20°C (68°F) 20°C (68°F) 20°C (68°F) 24°C (75°F) 24°C (75°F) 24°C (75°F)
TO1 Ramp HR1 CR1 HR1 CR1 OFF HR1 HR1
TO1 Signal Type On/Off On/Off On/Off On/Off On/Off On/Off On/Off
TO1 Close Pos. 40% 40% 40% 40% 40% 35% 35%
TO1 Open Pos. 0% 0% 0% 0% 0% 0% 0%
TO2 Ramp HR1 HR1 HR1 CO
2
OFF HR1 HR1
TO2 Signal Type Pulse On/Off Pulse On/Off On/Off On/Off On/Off
TO2 Close Pos. 40% 40% 40% 40% 40% 70% 70%
TO2 Open Pos. 0% 0% 0% 0% 0% 35% 35%
TO3 Ramp HR2 CR2 HR2 HR1 OFF Fan ON Fan Auto
TO3 Signal Type On/Off On/Off On/Off On/Off On/Off On/Off On/Off
TO3 Close Pos. 40% 40% 40% 40% 40% 40% 40%
TO3 Open Pos. 0% 0% 0% 0% 0% 0% 0%
TO4 Ramp HR2 HR2 HR2 HR1 OFF HR1 HR1
TO4 Signal Type Pulse On/Off Pulse On/Off On/Off On/Off On/Off
TO4 Close Pos. 40% 40% 40% 40% 40% 40% 40%
TO4 Open Pos. 0% 0% 0% 0% 0% 0% 0%
Motor Ramp CR1 COr COr COr CR1 CR1 COr
AO1 ramp HR1 CR1 HR1 CR1 HR1 HR1 HR1
AO2 Ramp HR2 HR1 HR2 HR1 OFF HR2 Fan Auto
AI1 Input OFF SENS SENS SENS OFF OFF SENS
AI2 Input OFF OFF OFF CO
2
OFF OFF OFF
DI1 Input nSb.o nSb.o nSb.o Occ.o Occ.o nSb.o nSb.o
Heat Prop Band 2 2°C (4°F) 2°C (4°F) 2°C (4°F) 2°C (4°F) 2°C (4°F) 1°C (2°F) 1°C (2°F)
Heat Deadband 2 1.3°C (2.6°F) 1.3°C (2.6°F) 1.3°C (2.6°F) 1.3°C (2.6°F) 0.3°C (0.6°F) 1.3°C (2.6°F) 1.3°C (2.6°F)
Cool Deadband 2 1.3°C (2.6°F) 1.3°C (2.6°F) 1.3°C (2.6°F) 1.3°C (2.6°F) 0.3°C (0.6°F) 0.3°C (0.6°F) 0.3°C (0.6°F)
Legend
Grey Text = Standard default value
Bold Text = Special default value for selected application
HR = Heating ramp
CR = Cooling ramp
COr = Changeover ramp
SENS = Changeover temperature sensor
Fan ON = Fan powered box in continuous mode
Fan Auto = Fan powered box in automatic mode (follows demand)
nSb.o = Night Setback (normally open)
Occ.o = Occupancy mode (normally open)
TO = TRIAC output
AO = Analog output
AI = Analog input
DI = Digital input
