Neptronic EVCB14NIT2S - Page 3

Networkable VAV Controller
Specification and Installation Instructions
www.neptronic.com EVCB Standard Page | 3
Dimensions
TRL24 TDU
A = 2.85” | 73mm
B = 4.85” | 123mm
C = 1.00” | 24mm
D = 2.36” | 60mm
E = 3.27” | 83mm
A = 4.94” | 125mm
B = 2.87” | 72.8mm
C = 3.44” | 87mm
D = 1.22” | 31mm
E = 0.75” | 19 mm
F = 2.00” | 51mm
G = 2.18” | 55mm
TDU Models
Model # Temp RH CO
2
PIR Colo
r
TDU10-100
●
grey LCD
white enclosure
TDU10-101
● ●
TDU10-102
● ● ●
TDU10-103
● ●
TDU10-104
● ●
TDU10-105
● ● ●
TDU10-106
● ● ● ●
TDU10-107
● ● ●
TDU10 Series
Model # Temp RH CO
2
PIR Colo
r
TDU40-100
●
black LCD
black enclosure
TDU40-101
● ●
TDU40-102
● ● ●
TDU40-103
● ●
TDU40-104
●
●
TDU40-105
● ●
●
TDU40-106
● ● ●
●
TDU40-107
● ●
●
TDU40 Series
Model # Temp RH CO
2
PIR Colo
r
TDU70-100
●
black LCD
white enclosure
TDU70-101
● ●
TDU70-102
● ● ●
TDU70-103
● ●
TDU70-104
●
●
TDU70-105
● ●
●
TDU70-106
● ● ●
●
TDU70-107
● ●
●
TDU70 Series
