Neptronic EVCBM14NIT2S - Page 4

Networkable Dual Duct VAV Controller
Specification and Installation Instructions
www.neptronic.com EVCBM – Dual Duct Page | 4
Interface
TRL24
Cooling ON
A: Automatic
Communication Status
Alarm status
Heating ON
A: Automatic
Menu Locked
Energy saving mode
(NSB or Occupancy)
Fan ON
A: Automatic
Programming mode
(Technician setting)
Percentage of
humidity
or
ºC: Celsius scale
ºF: Fahrenheit scale
TDU
Network
Communication
User Lock
Programming Mode
(Technician Setting)
Alarm Status
Energy Saving
Mode (NSB/OCC)
Schedule
Time
ppm
Parts Per Million
°C
°F
%RH
ºC: Celsius Scale
ºF: Fahrenheit Scale
%RH :Humidity
A
Automatic Mode
Cooling
Heating
Fan
BACnet or Modbus Address DIP Switch (DS1)
MAC address for communication, are selectable by DIP switch using binary logic. If you do not change device instance in program mode, it will be
automatically modified according to the MAC address.
Note: Avoid using addresses above 246 when selecting Modbus MAC address.
MAC Address
DS.1 = 1
DS.2 = 2
DS.3 = 4
DS.4 = 8
DS.5 = 16
DS.6 = 32
DS.7 = 64
DS.8 = 128
Default Device Instance
0
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
153000
1
ON
OFF
OFF
OFF
OFF
OFF
OFF
OFF
153001
2
OFF
ON
OFF
OFF
OFF
OFF
OFF
OFF
153002
3
ON
ON
OFF
OFF
OFF
OFF
OFF
OFF
153003
4
OFF
OFF
ON
OFF
OFF
OFF
OFF
OFF
153004
…
…
…
…
…
…
…
…
…
…
126
OFF
ON
ON
ON
ON
ON
ON
OFF
153126
127
ON
ON
ON
ON
ON
ON
ON
OFF
153127
* Slave addresses available by setting DS.8 to ON
C
F
%RH
MO TU WE TH FR SA SU
AM
PM
.
.
.
.
%RH
C
F
AM
PM
%RH
F
C
1 2 3 4 5 6 7
