MACH 10 Residential Ultrasonic Meter Installation and Maintenance Guide 21
Activating and Reading MACH 10 Ultrasonic Meters
Endpoint Reading Resolution
The reading resolution sent to the reading software is dependent on the
endpoint to which the encoder is connected. Readings reported from the
endpoints are the left-most significant digits of the encoder reading.
See Table 10.
Wiring Chart
Refer to Table 11 for wiring considerations.
Table 10 Reading Resolution
ProRead Resolution
Size Gallons Cubic ft Cubic m
5/8 10 1 0.1
3/4 10 1 0.1
11010.1
Table 11 MACH 10 Wiring Chart
MIU Wire Color / MACH 10 Wire Color MIU Type
Black/B Green/G Red/R R900
Black/B Green/G Red/R R450
Black/G Green/R Red/B Sensus
Black/B White/G Red/R Itron
Black/G White/R Red/B Aclara
Black/G Green/B Red/R Elster
Black/G Green/R Red/B Badger
