TG24/48 LIGHTING CONTROLLER PAGE: 3
1.2 Specification parameter
TG24 TG48
DMX512/1990 OUTPUT SIGNAL Yes Yes
CONTROLLABLE DMX512 CHANNEL 24 48
DIMMING CHANNEL 24 48
MAX SCENE 96 96
MAX CHASE 24 24
CHASE SPEED RANGE 0.03s~180s
CHASE TRIGGER MODE Auto, Music
CHASE DIRECTION CONTROL Forward / Inversion
LCD MONITOR Yes
MUSIC SIGNAL INPUT Unbalanced line level input
(1/4” Monophonic audio input)
/ MIC input
DMX512 OUTPUT PORT Optical isolated output port
ELECTRIC POWER SOURCE Switch mode power, voltage range:
100~240VAC, frequency: 50/60, short-circuit
protection & overload protection
POWER 5W
SIZE 482mm x 310mm x 95mm
2 Installation
TG24/48 lighting controllers’ packing chest contents items as following:
z One TG24/48 lighting controller:
Ps: to confirm the model of the controller, please check the model number and
software version number displayed on the LCD monitor when run the controller.
z One feed cable; one user’s guide.
The controller is of international 19” construction standard of installation. It can be in board
installed or installed on the 19” stander or machine cabinet.
2.1 Safety caution
z The controller must be connected with the protective groundwire to ensure safety.
z The intelligent Fixtures controller is sophisticated electronics. Please mind the dust
and moist.
