LIST OF PARTS
Main parts for all modes
Continued on the next page
Part Description Cat. No.
1
Aluminum frame for BP PL, BP ST, IL PL, IL ST Not availabe as spare part
2
Aluminum frame for High-flow, Octa Not availabe as spare part
3
Control unit Per NetaJet™ 4G serial number*
4
Dosing channels See Dosing channels, page 42
5
Venturis See Venturis table, page 43
6
Dosing booster See Dosing boosters, page44
7
Inlet for IL PL 33152- 002010
8
Pressure gauge, 250 GLZ 8 bar ¼" BSP 77540-003350
9
Vacuum gauge, model 250-1-9 ATM ¼" BSP 77540 - 004151
10
EC sensor, Jumo - 12 mm ,temperat comp. PT 100 45000-006705
11
pH sensor, Jumo - 12 mm, glass, BNC plug 45000-006692
12
Union adaptor set for EC/pH sensor 33140-008500
13
Barak plastic air valve ¾" BSP (DG-010) 70500-000540
14
Needle valve, ½" 76 4 0 0 - 011375
15
Upper manifold for BP PL, BP ST, IL PL, IL ST 33152- 001520
16
Upper manifold for High-flow, Octa 33152- 001070
17
Lower manifold for BP PL, BP ST, IL PL, IL ST 33152- 001530
18
Lower manifold for High-flow, Octa 33152-001000
19
Pump inlet for BP PL 33152-001600
20
Pump inlet for IL PL 33152-002020
21
Pump inlet for High-flow 33152-001200
22
Pump inlet for Octa 33152-001300
23
Pump outlet for BP PL 33152- 001610
24
Pump outlet for High-flow 33152- 001210
25
Pump outlet for IL PL 33152- 002030
26
Pump outlet, 50 mm for IL ST with CRI 10 pump 33152- 002270
Pump outlet, 63 mm for IL ST with CRI 15 / CRI 20 pump 33152- 002260
27
Strainer for IL ST 33152-002280
28
Pump outlet for Octa 33152-001310
29
PSV inlet for BP PL 33152- 001630
30
PSV inlet for High-flow, Octa 33152- 001040
31
PSV inlet for IL PL 33152- 002040
32
PH manifold for BP PL, BP ST, IL PL, IL ST 33152- 001510
33
PH manifold for High-flow, Octa 33152-001060
34
EC manifold for BP PL, BP ST, IL PL, IL ST 33152- 001500
35
EC manifold for High-flow, Octa 33152- 001010
36
PRV inlet for BP PL, BP ST 33152- 001400
37
PRV inlet for High-flow, Octa 33152- 001050
38
Pressure switch 1-3 bar 0.3 bar diff. ¼" 77800-002180
