Netafim NETAJET 4G User Manual

NETAJET
™
4G USER MANUAL 41
* To order spare parts, call your local Netafim™ local representative with the serial number of your NetaJet™ 4G
at hand. Only with this number we can supply the correct part for your specific NetaJet™ 4G.
The serial number is inscribed on the side of the switchbox (3530-_________).
LIST OF PARTS
Main parts for all modes (continued)
Part Description Cat. No.
39
Low-flow compensation channel set 33240-007000
40
Low-flow 1" PRV P-BSP-FF-A Dir. Act., Yellow cap 71000-016380
41
High-flow compensation channel set 33152-001080
42
High-flow 1" PRV P-SP-FF-B Dir. Act., White cap 71000-016100
43
Mixing chamber for BP PL, BP ST 33152-001700
44
Mixing chamber for High-flow, Octa 33152- 001020
45
Mixing chamber for IL PL 33152-002060
46
Mixing chamber for IL ST 33152- 002230
47
PSV, 1½" for for BP PL, IL PL 71600-001912
48
PSV, 2" for High-flow, Octa, IL ST 71600-010611
49
PSV outlet for BP PL 33152- 001620
50
PSV outlet for High-flow, Octa 33152- 001030
51
PSV outlet for IL PL 33152- 002050
52
PRV, 1½" for BP PL, BP ST, IL PL, IL ST 71600-001913
53
PRV, 2" for High-flow, Octa 71600-010612
54
PRV outlet for BP PL, BP ST 33152- 001410
55
PRV to PH manifold for IL PL 33152-002000
56
PRV to PH manifold for IL ST 33152- 002250
57
Outlet for BP ST 33152- 001810
58
Outlet for IL PL 33152- 002070
59
Outlet for IL ST 33152- 002240
60
Outlet from lower manifold for BP ST 33152-001800
61
Outlet from lower manifold for IL ST 33152-002200
Elbow, 90 deg. 3/4" F x 3/4" M 77300-011400
62
Inlet flange, 50 mm for IL ST with CRI 10 pump 33152-002220
Inlet flange, 63 mm for IL ST with CRI 15 / CRI 20 pump 33152- 002210
